3KW High Voltage Coolant Heater

PTC Heater

High Voltage Coolant Heater



Low voltage range	9-36V	Working temperature	-40 ~+85℃
Rated power	3KW	Storage temperature	-40 ~+105℃
High voltage range	70-110V	Coolant temperature	40 ~+90℃
Insulation resistance	voltage 500VDC,test for 60s,insulation resistance 100MQ	Protection level	IP67
Nsulation withstand voltage:	voltage 1220VAC,50Hz,no damage to the insulation layerafter testing,for 60s,leakage current 10mA	Product weight	2.1KG±5%

The role of PTC heaters in electric vehicles

PTC heaters play a variety of key roles in electric vehicles, mainly in the following aspects:

Car interior heating: In cold weather, PTC heaters are used in the heating module of the air conditioning system to transfer heat to the interior of the car by heating the air or coolant to increase the interior temperature and ensure passenger comfort.

Battery preheating: The performance of electric vehicle batteries will significantly decrease in low temperature environments, affecting the cruising range and charging and discharging efficiency. The PTC heater can preheat the battery to keep it within the optimal operating temperature range, improving battery performance and service life.

Defrosting and defogging: The PTC heater can be installed near the windshield to heat the glass surface to quickly remove frost and fog to ensure clear vision for the driver and improve driving safety.
