Caravan Diesel Heater Similar To Truma D6e
Water and air integrated heater for RV is a special heater for caravan that integrates hot water and warm air. This heater cannot be used in bus or dangerous goods carriers. Hebei Nanfeng Group is the largest manufacturer of heating and cooling equipment in China and the designated supplier of Chinese military vehicles.
Description
Caravan Diesel Heater Similar to Truma d6e
Products Description
Control Panel:
Structure and composition
Hot water heating part: The hot water heater and air all-in-one machine heats water through gas, electricity, etc., and transports the heated hot water to each heating port through pipes.
Warm air heating part: There is a fan and air channel inside the all-in-one machine. The heated hot water exchanges heat with the air through the heat exchanger to generate hot air, which is then sent into the room through the fan.
Control system: The hot water heater and air all-in-one machine is equipped with an intelligent control system, which can automatically adjust the heating water temperature, wind speed, etc. according to indoor temperature, user needs and other parameters to achieve intelligent control and energy-saving operation.
Products Parameters
| Rated Voltage | DC12V |
| Operating Voltage Range | DC10.5V～16V |
| Short-term Maximum Power Consumption | 8-10A |
| Average Power Consumption | 1.8-4A |
| Fuel type | diesel/petrol |
| Gas Heat Power (W) | 2000 4000 |
| Fuel Consumption (g/h) | 240/270 |
| Gas Pressure | 30mbar |
| Warm Air Delivery Volume m3/h | 287max |
| Water Tank Capacity | 10L |
| Maximum Pressure of Water Pump | 2.8bar |
| Maximum Pressure of System | 4.5bar |
| Rated Electric Supply Voltage | ～220V/110V |
| Electrical Heating Power | 900W 1800W |
| Electrical Power Dissipation | 3.9A/7.8A 7.8A/15.6A |
| Working (Environment) Temperature | -25℃～+80℃ |
| Weight (kg) | 15.6kg |
| Dimensions (mm) | 510×450×300 |
| Working Altitude | ≤1500m |
Installation and Application
Application process
Set temperature and wind speed: Before using the hot water heater and air blower, set the appropriate temperature and wind speed as needed. It can be adjusted automatically according to the indoor temperature or manually.
Regular maintenance: Clean and maintain the hot water heater and air integrated machine regularly to keep the equipment clean and in normal operating condition and extend the service life of the equipment.
Energy-saving use: During actual use, the temperature and wind speed should be reasonably controlled to avoid excessive energy consumption, save energy, and reduce usage costs.
Safety precautions: When using the hot water heater and air heater, pay attention to the safe use of the equipment and avoid long-term continuous use to prevent malfunctions or safety accidents.
Indoor air circulation: When using a hot water heater and air heater, maintaining indoor air circulation and opening windows for ventilation in a timely manner will help improve indoor air quality.
