Self-generating Portable Diesel Heater

We are a heating and cooling factory in China with more than 30 years of experience.In China we provide it to Chinese army vehicle, it can represent the highest level of quality in Chinese water parking heaters.

Send Inquiry

Description

Self-generating portable diesel heater

Products Description

The product application field and use of this product are especially suitable for occasions that require no external power and require a heat source, such as field work, outdoor travel adventure, Emergency Support, Emergency Rescue, Military garrison drills, and other occasions. The utility model can be used for heating mobile and temporary facilities such as automobiles, ships, camping tents, and other temporary buildings.

Use Safety and precautions
Objects around the heater must be prevented from being affected or damaged by high temperatures.
When in use, the exhaust gas must be discharged outside the user's heating space to prevent it from entering through the ventilation device or windows.
The exhaust pipe must avoid flammable materials, to avoid the exhaust pipe's high temperatures caused by fire.
You may not use parts from other manufacturers or change the heater on the key components without the company's permission.
It is not permitted to use the heater where flammable steam or dust may form. The heater must be turned off when refueling.
If fuel is found to be leaking out of the heater fuel system, return to the service station immediately for maintenance.

Item Name	parking heater	Rated Voltage(Max)	16.8V
Heating medium	Air	Heat Level	1-9
Fuel	Diesel	Heat rating	1KW-4KW
Weight	13KG	Fuel consumption	0.1L/h-0.4L/h
Size(mm)	410265280mm	Power consumption	＜40W
Certification	CE	Brand	NF
Special vehicles	The water-cycling system of mid-size cars, SUVs, trailers,wagons, vans, etc

heater

installation

Failure maintenance and service

Code	Possible failure	Measures
E-1X	Abnormal voltage	1, Check if the positive and negative stages of the battery are installed correctly
		2, The battery needs to be charged or replaced.
E-2X	TemperatureSensor failure	1, Check if the air inlet/outlet pipe is blocked.
		2, Check if the plug of the sensor is loose.
E-3X	Glow Plug pin failure	1, Check that the ignition plug in the heater is loose
E-4X	The oil pump failure	1, Check if the oil pump plug is loose.
		2, Check if the oil pump is blocked
E-5X	Combustion fan failure	1, Check if the plug of the combustion motor is loose.
		2, ls the combustion fan running too loud.
E-7X	Ignition failed	1, Check the Air valve of the fuel tank is opened.
		2, Check if there is enough fuel in the tank.
E-8X	Flame out during combustion	1, Check if there is any fuel l leakage in the fuel circuit.
		2, Check whether the oil pump is working or not and whether it is cut off or not fueled
