Oil-free Piston Air Compressor
Hebei Nanfeng Automobile Equipment (Group) Co.,Ltd, which is the only designated parking heater supplier for the Chinese military vehicle. Our products are not only popular in China, but also exported to other countries, like South Korea, Russia, Ukraine, and so on.
Description
Oil-free piston air compressor
A. Compact structure
The permanent magnet motor is integrated with the cylinder frame, so the whole machine is small in size and light in weight, which greatly reduces the appearance size.
B. Low noise
The noise of the piston air compressor mainly comes from the air intake link. Through the optimized design of the cylinder head, cylinder tube and air intake system, the noise is reduced to below 72db, which is more in line with environmental protection requirements.
C. Lightweight design
The aluminum main engine weighs only 52 kg, which reduces the weight of the entire vehicle and saves energy for customers.
D. High adaptability
It has excellent adaptability and reliability to the ambient temperature, and can adapt to the working environment of -45℃~+65℃.
E. Super coating
The inner wall of the cylinder adopts super coating, which has good air tightness and little wear, which can prolong the service life of the whole machine.
F. Longer life
The machine adopts imported high-temperature bearings to ensure that the grease will not be lost and the life of the whole machine.
G. Low cost maintenance fee
The main engine has fewer parts, fewer wearing parts and low maintenance costs. At the same time, it does not require lubricating oil, saves oil consumption, does not need frequent maintenance, and saves
money and worry
| HV oil-free piston engine | HVG oil-free live rich machine | |||
| 1.5KW | 2.2KW | 3.0KW | 4.0KW | |
| Displacement (㎡/min) | 0.15 | 0.2 | 0.26 | 0.38 |
| Rated speed (r/min) | 1500 | 1500 | 1100 | 1100 |
| Work pressure (Mpa) | 1.0 | 1.0 | 1.0 | 1.0 |
Maximum pressure (Mpa) | 1.2 | 1.2 | 1.2 | 1.2 |
| Vibration (mm/s) | 28 | 28 | 28 | 28 |
Noise dB(A) | 72 | 75 | 75 | 75 |
Noise dB(A) | -40~65 | -40~65 | -40~65 | -40~65 |
| Protection level | IP68 | IP68 | IP68 | IP68 |
| Weight (kg) | 32 | 45 | 46 | 52 |
| Exhaust port size | M22*1.5 | M22*1.5 | M22*1.5 | M22*1.5 |
| Installation size (mm) | 260*190 | 330*260 | 330*260 | 330*260 |
| Dimensions (mm) | 495*308*396 | 495*370*377 | 495*370*377 | 522*383*385 |
A. No need to add lubricating oil
No need to add lubricating oil, the exhaust gas does not contain oil,
which eliminates the adverse consequences of oily gas on the production
process, and will not pollute the user's end product
B. No lubricating oil
Does not contain lubricating oil, will not produce the adverse effects of
lubricating oil solidification in low-temperature engineering and
lubricating oil emulsification in high-temperature and humid
environments
C. Gas without oil
The gas does not carry oil, which reduces and eliminates the possibility
of oil deposits on the wall of the heat exchanger, improves the heat
exchange efficiency and reduces the resistance loss of the gas.
Application range:
➢ Brake system
➢ Air suspension system
➢ Can open the door
➢ Windshield wiper
