New Electric PTC Water Heater For EV
Hebei Nanfeng Group is China's largest manufacturer of automotive heating and cooling equipment, has been producing heaters for more than 30 years, and is the designated supplier of Chinese military vehicles. With the rise of new energy electric vehicles, our new electric PTC water heater for EV has a good development prospect. This electric heater has the advantages of high energy efficiency and cost saving.
Description
New electric PTC water heater For EV
1、Product Introduction
Our high pressure coolant heaters can be used to improve battery energy performance in electric and hybrid vehicles. In addition, it produces a comfortable cabin temperature in a short period of time, resulting in a better driving and passenger experience. Due to their low thermal mass, high thermal power density and fast response time, these heaters also extend electric-only driving range because they use less electricity from the battery.
This electric heater is specially designed for electric vehicles. It is heated by PTC components, which can well convert electrical energy into heat energy. At the same time, the heater can be used in both driving mode and parking mode of the vehicle. And this heater has a short-term heat storage function, which is also very environmentally friendly.
2、Product Parameter
| Item | WPTC-13 |
| Rated voltage(V) | 430V |
| Rated power | 8KW |
| Ambient temperature | -40~105℃; Ambient humidity: 5%~90%RH; Medium: 50% water/50% ethylene glycol; |
| Heater weight | 3.7±0.1Kg |
| Heater protection grade | IP67 |
| Heater air tightness | Apply pressure 0.6MPa, test for 3min, the leakage is less than 500Pa |
Structure：
3、Product Feature
(1)Almost 100% heat output.
(2)Heat output independent of coolant medium temperature and operating voltage.
(3)Seamlessly, quickly and precisely controllable.
(4)Direct, fast heat transfer.
4、Product Detail
5、Installation advice
(1)The highest point of the PTC should be lower than the expansion tank.
(2)The water pump should not be higher than the PTC.
(3)The PTC should be installed after the water pump and before the heater core.
(4)Pay attention to the direction of the PTC in and out of the water.
(5)Before the PTC works for the first time, or after the maintenance of the pipeline components, the water pump should be operated first, and the exhaust should be confirmed, and then the PTC should be powered on.
6、Product Application
7、Product Qualification
8、FAQ
(1)Q:How your quality guarantee?
A:We have 100% quality guarantee to customers. We will be responsible for any quality problem.
(2)Q:Can we visit your factory before place the order?
A:Yes,Very welcome that must be nice to set up good relationship for business.
(3)Q:Would you have a discount if l have a large order?
A:Yes we could offer different discount according to your order quantity.
(4)Q: What's your tem of the delivery?
A: Our ordinary delivery term is FOB Beijing. We also accept EXW, CFR, CIF, DDP, DDU etc. We’ll offer you the shipping charges and you can choose the one which is the most convenient and effective for you.
(5)Q:Where is your factory located?
A:It lies in the industrial area of Wumaying of Nanpi county of province Hebei, covers an area of 80,000㎡.
