Diesel Combination Air And Electric Water Heater For Caravan
Diesel combination air and electric water heater for caravan is a special heater for caravan that integrates hot water and warm air. This heater cannot be used in bus or dangerous goods carriers. Hebei Nanfeng Group is the largest manufacturer of heating and cooling equipment in China and the designated supplier of Chinese military vehicles.
Description
Diesel Combination Air And Electric Water Heater For Caravan
Products Description
The diesel combi heater is a warm-air heater with an integrated hot water boiler. This unit was designed for installation in motorhomes, boats, and caravans.
The diesel combination heater is a warm-air heater with an integrated hot water tank. We designed this diesel combination air/water heater for installation in motor homes and caravans.
Products Parameter
| Rated Voltage | DC12V |
| Operating Voltage Range | DC10.5V～16V |
| Short-term Maximum Power Consumption | 8-10A |
| Average Power Consumption | 1.8-4A |
| Fuel type | diesel/petrol |
| Gas Heat Power (W) | 2000 4000 |
| Fuel Consumption (g/h) | 240/270 |
| Gas Pressure | 30mbar |
| Warm Air Delivery Volume m3/h |
287max |
| Water Tank Capacity | 10L |
| Maximum Pressure of Water Pump |
2.8bar |
| Maximum Pressure of System | 4.5bar |
| Rated Electric Supply Voltage | 220V/110V |
| Electrical Heating Power | 900W 1800W |
| Electrical Power Dissipation |
3.9A/7.8A 7.8A/15.6A |
| Working (Environment) Temperature | -25℃～+80℃ |
| Weight (kg) | 15.6kg |
| Dimensions (mm) | 510×450×300 |
| Working Altitude | ≤1500m |
Products Structure
Working Principle:
This heater is a combination of hot water and warm air, which can provide hot water while heating the compartment. It can be used while driving.
There are 2 working mode to select during working (hot water and warm air working mode and hot water working mode)
In hot water and warm air mode, the heater can be used to heat both the room and the hot water. If hot water is needed only, pls choose the hot water working mode.
Attention: when the ambient temperature is below 3℃, please empty the water tank to avoid the water freezing in the tank.
Products Details
LCD Digital Control Panel
● Monitor working status.
● Check exact temperature.
● HD display panel.
● Error code check automatically.
Products Packing
Products Certification
FAQ
1、Q:Where is your factory located?
A:It lies in the industrial area of Wumaying of Nanpi county of province Hebei, covers an area of 80,000㎡.
2、Q:What is your minimum order quantity, can you send me samples?
A：Our MOQ is one set, samples are available.
3、Q:About the after-sale service, how can you solve the problems occurred of your overseas customer in time?
A:Our warranty period is one year, and our service staff will do their best to solve any problems you have.
4、Q:How you arrange shipment?
A: By Sea/By Air/By Train/By Express.
5、Q:Can we visit your factory before place the order?
A:Yes,Very welcome that must be nice to set up good relationship for business.
