220V RV Overhead Air Conditioner
Hebei Nanfeng Group is the largest manufacturer of automobile heating and cooling equipment in China and the designated supplier of military vehicles in China.This overhead air conditioner has the advantages of low noise and fast cooling.
Description
220V RV Overhead Air Conditioner
Products Description
This machine is designed and installed to suit RVs to improve their interior temperature and provide a comfortable environment. It can cool the RV when it is hot and heat it when it is cold. Its temperature can be adjusted in both environments.
Installation Environment of Air Conditioner
(1)It can be installed during the production or after the completion of RV.
(2)The air conditioner can only be installed horizontally on the top of the RV.
(3)The minimum spacing between rafters and joists on the roof structure is 400mm.
(4)The minimum thickness of the roof of RV is 26mm and the maximum thickness is 100mm.
(5)When the roof thickness is greater than 100mm, additional air duct is required for connection.
Products Parameter
| Model |
NFRTN2-100HP |
NFRTN2-135HP |
| Rated Cooling Capacity | 9000BTU | 12000BTU |
| Rated Heat Pump Capacity | 9500BTU | 12500BTU(but 115V/60Hz version has no HP) |
| Power consumption(cooling/heating) | 1000W/800W |
1340W/1110W |
| Electric current(cooling/heating) | 4.6A/3.7A | 6.3A/5.3A |
| Compressor stall current | 22.5A |
28A |
| Power Supply | 220-240V/50Hz, 220V/60Hz | 220-240V/50Hz, 220V/60Hz, 115V/60Hz |
| Refrigerant |
R410A |
|
| Compressor | Horizontal type, Gree or others | |
| Upper Unit Sizes (L*W*H) |
1054*736*253 mm |
1054*736*253 mm |
| Indoor panel net size | 540*490*65mm | 540*490*65mm |
| Roof opening size | 362*362mm or 400*400mm | |
| Net weight of roof host | 41KG | 45KG |
| Indoor panel net weight | 4KG | 4KG |
| Upper Unit Sizes (L*W*H) | PP Plastic Injection cover, metal base | Inner frame material: EPP |
Products Details
Interior Control Panel
Products Application
